2010 Nickey Stage II CNC'ed Heads

[Stefano]

[image][/image]
[image][/image] [image][/image] [image][/image] [image][/image]

[elonblock]

It's like a piece of artwork.
Beautiful!

[Stefano]

I just amazes me with what they can get those machines to do.

[70 Forest Green Zee]

Steve....do you have a head that hasn't been machined so you could put them side by side and we all could see the difference between the two?

[Stefano]

I'll take some on the next set we do. This is looking to be a popular upgrade. Check out the flow bench results.

Nickey Stage II 600HP Head Package

Wegner Motorsports LS3/L92 CNC Ported Head Info

• Brand New GM Castings
• 5 axis CNC Ported and custom 5 angle valve job
• Dyno Tested 25+ HP gain
• NASCAR Proven in weekly racing series
• 2.165 Intake Valve and 1.59 Exhaust valve
• 68cc Chamber, 96cc Exhaust, 279cc Intake
• Comes with Manley Stainless Valves standard and Titanium or Hollow Stem Intake valves are options for High RPM
• Comes with PSI Beehive Springs, Wegner Motorsports Retainers, GM Valve Seals, Wegner Motorsports Spring Seats, Dual springs available also



Lift Intake Exhaust
0.100 70.4 51.4
0.200 152.5 105.3
0.300 216.0 145.4
0.400 261.7 175.8
0.500 306.0 202.1
0.600 337.4 226.6
0.700 360.5 232.6

Flowed on 4.060" Bore and no pipe

We are getting 600 fwhp with the heads, our special cam, the fast intake, our headers X-pipe and a tune.

We hope to have this car at the Super Car reunion for some track testing

[Stefano]

Nickey Stage II 600HP Head Package

(You will also need a fast intake, headers, exhuast and a tune.)

Wegner Motorsports LS3/L92 CNC Ported Head Info

• Brand New GM Castings
• 5 axis CNC Ported and custom 5 angle valve job
• Dyno Tested 25+ HP gain
• NASCAR Proven in weekly racing series
• 2.165 Intake Valve and 1.59 Exhaust valve
• 68cc Chamber, 96cc Exhaust, 279cc Intake
• Comes with Manley Stainless Valves standard and Titanium or Hollow Stem Intake valves are options for High RPM
• Comes with PSI Beehive Springs, Wegner Motorsports Retainers, GM Valve Seals, Wegner Motorsports Spring Seats, Dual springs available also



Lift Intake Exhaust
0.100 70.4 51.4
0.200 152.5 105.3
0.300 216.0 145.4
0.400 261.7 175.8
0.500 306.0 202.1
0.600 337.4 226.6
0.700 360.5 232.6

Flowed on 4.060" Bore and no pipe[/QUOTE]

Price for the New Heads, cam and all the parts needed to assemble this Kit is $2,250.00 plus shipping and handling. No core exhange!

Please contact Dan Timm @ Wegner Motor Sports to place your order.

http://www.wegnerautomotive2.com/

[Salvatore]

Looks like some real go fast parts! Real nice work!

[Stefano]

Thanks! Here is the dyno results.

Engine Dyno Results for the Nickey Stage II Natualy aspirated Option.

603 hp @ 6400 RPM
534 HP @ 5300 RPM

https://www.youtube.com/user/WegnerMotorsports

[Stefano]

[Stefano]

We added a Magnuson Supercharger on top of the 600hp Stage II and achieved over 750fwhp!
